Fawde 150kw Genset Diesel Engine for Sales
Product Description
WE ARE MANUFACTURER!
Products Features:
1.We cooperate with famous diesel engine -Powered By Deutz , Lovol, Doosan, Shangchai, Yanmar, Foton-Isuzu, FAWDE, SDEC, Weichai, Yuchai, Ricardo, Jichai, Quanchai, Yandong,Kubota ETC
2. Equipped with famous Brushless Alternator - Optional Stamford, Leroy Somer, Marathon, BOBIG, Mecc alte.
3. Equipped with 50°C radiator with fan, enough Engine cooling system guarantee long time working
4. Equipped with advanced generator set control system, ATS system, remote control system, parallel operation system, optional control model, Deep sea, Smartgen , ComAp ,r5. Generator set use High-quality steel are thickness canopy -- 2MM to 6MM
6. Equipped with high density sound-absorbing material -- sound insulation, fireproofing
7. Generator equipped with 12V/ 24V DC battery with charger, battery connects wire.
8. Generator equipped with 10-12 hours fuel tank with fuel indicator, long time for working.
9. High protect class control box and power output box. IP55, Waterproof, Electric leakage protect, Breaker
10. New design of turn-back type for air inflow & air outlet which can reduce the noise and improve engine efficiency.
11. Beautiful & practicably design, Bottom hole for forklift, Water outlet & oil outlet for easy maintenance
12. Double open door on both sides of the Gensets. Spacious doors can check for every part of the engine and alternator.
13. All new design for Diesel Generator set of Silent, Supper silent, Soundproof, Trailer type, Container type.
14. Our generator set compliance with all main standards, such as : GB/T2820, ISO8528,IEC34, CE, EPA Tier4 stand
Safety - Stability - Economy - Reliability Power
Our generator set compliance with all main standards, such as : GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard
Controller System
Standard AMF control panel, including digital LED genset control model: HGM6120, DSE7320, DSE6020, AMF20, AMF25
Manufacturing Standard
GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard ,GB755,BS 5000,VDE 0530, NEMA MG1-22,IEC34.
Product Warranty policy
BOBIG products has guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, we will provide the free easy-damageable spare parts, caused by our quality of production or raw material. After expiration, our provides cost spare parts maintenance.
Fawde Engine Company Brief Introduction:
FAWDE deepens the campaign of establishing "Safe Enterprise". Aiming to set up the concept of safe development, and reduce various accidents and cases, FAWDE has been honored the "Advanced Unit of Safety Production" by the People's Government of Wuxi for four consecutive years from 2008 to 2011. In 2011, it was awarded the honor of "Honest Enterprise of Safety Production of Jiangsu Province in 2010" by Jiangsu Province for its outstanding performance. FAWDE has been recognized by Jiangsu Province and Wuxi City and has been highly affirmed by the State as well for its work in establishing "Safe Enterprise". In 2008, in the assessment of "National Grade A Enterprise of Safety Quality Standardization" carried out by China Machinery Industry Association of Safety and Health, FAWDE was awarded National Grade A Enterprise of Safety Quality Standardization with a scoring rate of 96.101%.
Fawde diesel generator Set Range
Pictures:
Why BOBIG:
Products Features:
1.We cooperate with famous diesel engine -Powered By Deutz , Lovol, Doosan, Shangchai, Yanmar, Foton-Isuzu, FAWDE, SDEC, Weichai, Yuchai, Ricardo, Jichai, Quanchai, Yandong,Kubota ETC
2. Equipped with famous Brushless Alternator - Optional Stamford, Leroy Somer, Marathon, BOBIG, Mecc alte.
3. Equipped with 50°C radiator with fan, enough Engine cooling system guarantee long time working
4. Equipped with advanced generator set control system, ATS system, remote control system, parallel operation system, optional control model, Deep sea, Smartgen , ComAp ,r5. Generator set use High-quality steel are thickness canopy -- 2MM to 6MM
6. Equipped with high density sound-absorbing material -- sound insulation, fireproofing
7. Generator equipped with 12V/ 24V DC battery with charger, battery connects wire.
8. Generator equipped with 10-12 hours fuel tank with fuel indicator, long time for working.
9. High protect class control box and power output box. IP55, Waterproof, Electric leakage protect, Breaker
10. New design of turn-back type for air inflow & air outlet which can reduce the noise and improve engine efficiency.
11. Beautiful & practicably design, Bottom hole for forklift, Water outlet & oil outlet for easy maintenance
12. Double open door on both sides of the Gensets. Spacious doors can check for every part of the engine and alternator.
13. All new design for Diesel Generator set of Silent, Supper silent, Soundproof, Trailer type, Container type.
14. Our generator set compliance with all main standards, such as : GB/T2820, ISO8528,IEC34, CE, EPA Tier4 stand
Safety - Stability - Economy - Reliability Power
Our generator set compliance with all main standards, such as : GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard
Controller System
Standard AMF control panel, including digital LED genset control model: HGM6120, DSE7320, DSE6020, AMF20, AMF25
Manufacturing Standard
GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard ,GB755,BS 5000,VDE 0530, NEMA MG1-22,IEC34.
Product Warranty policy
BOBIG products has guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, we will provide the free easy-damageable spare parts, caused by our quality of production or raw material. After expiration, our provides cost spare parts maintenance.
Fawde Engine Company Brief Introduction:
FAWDE deepens the campaign of establishing "Safe Enterprise". Aiming to set up the concept of safe development, and reduce various accidents and cases, FAWDE has been honored the "Advanced Unit of Safety Production" by the People's Government of Wuxi for four consecutive years from 2008 to 2011. In 2011, it was awarded the honor of "Honest Enterprise of Safety Production of Jiangsu Province in 2010" by Jiangsu Province for its outstanding performance. FAWDE has been recognized by Jiangsu Province and Wuxi City and has been highly affirmed by the State as well for its work in establishing "Safe Enterprise". In 2008, in the assessment of "National Grade A Enterprise of Safety Quality Standardization" carried out by China Machinery Industry Association of Safety and Health, FAWDE was awarded National Grade A Enterprise of Safety Quality Standardization with a scoring rate of 96.101%.
Fawde diesel generator Set Range
| MODEL | PRIME POWER KW/KVA | STANDBY POWER KW/KVA | ENGINE MODEL | ENGINE POWER KW | STAMFORD TYPE | SIZE |
| BFA17S | 12/15 | 13.2/17 | 4D81-23D | 17 | BW-164D | 1700*880*1040 |
| BFA17 | 12/15 | 13.2/17 | 4D81-23D | 17 | BW-164D | 1400*610*1140 |
| BFA21S | 16/20 | 18/22 | 4D91-29D | 21 | BW-184E | 1900*880*1060 |
| BFA21 | 16/20 | 18/22 | 4D91-29D | 21 | BW-184E | 1400*610*1160 |
| BFA27S | 20/25 | 22/27.5 | 4D92-35D | 26 | BW-184F | 1900*880*1060 |
| BFA27 | 20/25 | 22/27.5 | 4D92-35D | 26 | BW-184F | 1400*610*1160 |
| BFA33S | 24/30 | 26/33 | 4DX21-45D | 33 | BW-184G | 2100*880*1120 |
| BFA33 | 24/30 | 26/33 | 4DX21-45D | 33 | BW-184G | 1550*610*1220 |
| BFA42S | 30/38 | 33/42 | 4DX22-50D | 37 | BW-184H | 2300*970*1200 |
| BFA42 | 30/38 | 33/42 | 4DX22-50D | 37 | BW-184H | 1800*710*1300 |
| BFA55S | 40/45 | 44/55 | 4DX23-65D | 48 | BW-224D | 2300*1000*1250 |
| BFA55 | 40/45 | 44/55 | 4DX23-65D | 48 | BW-224D | 2000*710*1350 |
| BFA77S | 56/70 | 66/77 | 4110/125Z-09D | 65 | BW-224F | 2500*1040*1200 |
| BFA77 | 56/70 | 66/77 | 4110/125Z-09D | 65 | BW-224F | 2000*710*1300 |
| BFA100S | 72/90 | 80/100 | CA4DF2-12D | 84 | BW-274C | 2900*1040*1480 |
| BFA100 | 72/90 | 80/100 | CA4DF2-12D | 84 | BW-274C | 2200*800*1580 |
| BFA113S | 80/100 | 90/113 | CA6DF2D-14D | 90 | BW-274C | 2900*1040*1480 |
| BFA113 | 80/100 | 90/113 | CA6DF2D-14D | 90 | BW-274C | 2200*800*1580 |
| BFA138S | 100/125 | 110/138 | CA6DF2-17D | 125 | BW-274D | 3100*1040*1480 |
| BFA138 | 100/125 | 110/138 | CA6DF2-17D | 125 | BW-274D | 2350*800*1580 |
| BFA165S | 120/150 | 132/165 | CA6DF2-19D | 140 | BW-274F | 3200*1040*1480 |
| BFA165 | 120/150 | 132/165 | CA6DF2-19D | 140 | BW-274F | 2500*800*1580 |
| BFA206S | 150/188 | 165/206 | CA6DL1-24D | 176 | BW-274G | 3200*1040*1480 |
| BFA206 | 150/188 | 165/206 | CA6DL1-24D | 176 | BW-274G | 2500*800*1580 |
| BFA250S | 180/225 | 200/250 | CA6DL2-27D | 205 | BW-274J | 3400*1300*1660 |
| BFA250 | 180/225 | 200/250 | CA6DL2-27D | 205 | BW-274J | 2600*1000*1760 |
| BFA275S | 200/250 | 220/275 | CA6DL2-30D | 227 | BW-274K | 3400*1300*1660 |
| BFA275 | 200/250 | 220/275 | CA6DL2-30D | 227 | BW-274K | 2600*1000*1760 |
Pictures:
Why BOBIG:
1. 15 years experience in supplying diesel generator sets and Gas Generator with different sorts of brand
2. We are Factory,you will have Factory price,Factory Quality,Factory Warranty.
3. Offer Super good service before and after sales,Respone your needs fast 7*24 hours
4. Our reputation for low prices, fast shipping and excellent customer service keeps customers coming back
FAQ:
1. What is your MOQ, payment method, delivery time?
Answer: Our MOQ is only 1 set. Payment method usually is 30% T/T as deposit, 70% balance T/T before delivering.
Or 100% L/C,tradeassurance,paypal,wester union..Delivery period normally will be 10~15 working days after receiving customers' deposit.
2. Which port do you often use when export?
Answer: Fuzhou port,Fujian province or as customer request.
3. Is there any spare parts you can provide along with genertors to make the maintenance convenient?
Answer: We can provide regular engine's air filter, water filter, fuel filter, oil filter to customers for self-maintenance.
4.Can you offer parts to us if we need?
Answer: Yes,we can offer parts to you at any time,not limited in warranty time.usually the parts can be sent out during 3-5days.
5. For voltage,frequency,tank capacity,phase and color,can you made accord with our requests?
Answer: Yes,they can be made accord with your need.
6. If I want to be your products distributor in our country, what is your distribution policy?
Answer: Welcomes everybody join us and distribute products worldwide. We can issue authority certificates and sign agreement with you accordingly.
2. We are Factory,you will have Factory price,Factory Quality,Factory Warranty.
3. Offer Super good service before and after sales,Respone your needs fast 7*24 hours
4. Our reputation for low prices, fast shipping and excellent customer service keeps customers coming back
FAQ:
1. What is your MOQ, payment method, delivery time?
Answer: Our MOQ is only 1 set. Payment method usually is 30% T/T as deposit, 70% balance T/T before delivering.
Or 100% L/C,tradeassurance,paypal,wester union..Delivery period normally will be 10~15 working days after receiving customers' deposit.
2. Which port do you often use when export?
Answer: Fuzhou port,Fujian province or as customer request.
3. Is there any spare parts you can provide along with genertors to make the maintenance convenient?
Answer: We can provide regular engine's air filter, water filter, fuel filter, oil filter to customers for self-maintenance.
4.Can you offer parts to us if we need?
Answer: Yes,we can offer parts to you at any time,not limited in warranty time.usually the parts can be sent out during 3-5days.
5. For voltage,frequency,tank capacity,phase and color,can you made accord with our requests?
Answer: Yes,they can be made accord with your need.
6. If I want to be your products distributor in our country, what is your distribution policy?
Answer: Welcomes everybody join us and distribute products worldwide. We can issue authority certificates and sign agreement with you accordingly.
